The SpeediChannel™ 230-SF4W 4 in. white soffit fitting by DiversiTech® is ideal for outdoor applications where the lineset runs up an exterior wall and enters the house vertically through the soffit.. Its large, flat surface area easily covers the rough opening cut in the soffit. The two-part soffit fitting easily snaps onto the channel for a clean installation.

Diversitech SpeediChannel™ Line Set Soffit Fitting, Series: 230, 4 in, For Use With: SpeediChannel™ System, Import

Features:

• For use with air conditioning line sets
• Paintable
• Includes Stainless Steel Screws
• Made of UV resistant PVC material to resist the elements and provide lasting protection

you will receive 2

SpeediChannel is the perfect universal installation system – combining high quality resins in a paintable natural color easily adapted to any colored mounting and SpeediClip, a unique sliding rail system that makes line set installation a one man job. DiversiTech SpeediChannel is easier to inventory, transport and install than competing brands, and the flat pack design reduces warehouse storage and contractor transport space. Tight fit corner design & installation accessories deliver the contractor a clean install every time.

The SpeediChannel 230-AFB4 4 in. natural color adjustable flat bend by DiversiTech bends flex from 45 to 90 degrees and makes it easy to route the line set around an obstacle. Each adjustable bend is individually packed and includes stainless steel screws.

Features

• UV Resistant
• Packed each separately in plastic film
• Ideal for outdoor applications
• Application: Air conditioning line sets
• Purpose: DiversiTech SpeediChannel is a system used to cover line sets, drain lines, and control cables when they can not be installed inside a wall
• Colorfast Stability: The stability of the color of the Product is such that after 5 years external exposure in the climate zone defined within following paragraph, the contrast on the Grey scale according to ISO EN 105 A02 of the finished goods made from the Product will not be below level 3, when compared to an unexposed control sample of the same grade. This statement is limited to the climate zones where the annual global irradiation is less than 100,000 Langleys: North American climate.
• Painting Specifications: DiversiTech recommends any 100% acrylic latex or 100% acrylic latex with a urethane additive when painting SpeediChannel products. The reason for this recommendation is because of the paint’s flexibility. Lacquers are not recommended with PVC products because lacquers are more brittle and won’t flex with the channel. Some suggestions: Duration by Sherwin Williams, Manor Hall paints by PPG and Moorelife by Benjamin Moore. In addition to paint type, only light to medium colored paints (Light Reflectance Value of 55% units or greater) should be applied to SpeediChannel or most any exterior PVC products. Light Reflectance Value (LRV) is a measurement that indicates how much light a color reflects. An LRV of 0% is absolute black and an LRV of 100% is perfectly reflective white. LRV is on the back of most color swatches and in the index of all major brands’ fandecks. It is not safe to assume the paint is a light color. Some paints that appear light beige can have an LRV in the 20s or 30s.
