Arrow E62-26-346-144-CS E Series Grade 2 Deadbolt

• Strike Size: 1-1/8″ x 2-3/4″
• Finish: Bright Polished Chrome
• Interior Lock Type: Keyed
• Exterior Lock Type: Keyed
• Finish Description: Bright Polished Chrome
• Function: 62-Cylinder x Cylinder Deadbolt
• Latch Type: Square Corner
• ANSI Function: 62
• Grade: ANSI/BHMA Grade 2
• ADA Compliant: No
• Keyblank Grouping: ARRW-C-6-1
• Front Size: 2-1/4″ x 1-1/8″
• Cylinder Type: Conventional Cylinder
• Deadbolt Throw: 1 Inch
• Strike: Deadbolt, 1-1/8″ x 2-3/4″, Square Corner
• Keying Charges: CCAM
• Deadbolt Material: Steel
• Standards: ANSI A156.5; UL and CUL Listed
• Cylinder Material: Solid Brass
• Product Type: Auxiliary Lock
• Rose/Escutcheon Trim: Round Rose
• Features: Tamper Resistant Rotating Wrench-Proof Collar; Two-Piece Housing; Reversible Handing; Hardened Free Spinning Steel Pin Insert Deadbolt
• Strike Type: Square Corner
• Backset: 2-3/4 Inch
• Keyway: Schlage C

Cylinder Type Used:  Conventional
