Arrow E62-26D E-Series Deadbolt Double Cylinder in Satin Chromium

The Arrow Lock E62-26D E Series deadlocks are known for value, quality and durability all wrapped up together. The tamper resistant rotating wrench-proof collar, steel deadbolt with hardened steel pin insert and the concealed screws are security features that have made the E Series the most specified deadlock around. This series are certified to BHMA A156.5, Grade 2, UL Listed. The deadbolt is thrown or retracted by key from outside or retracts and key retracts and projects bolt.

Features and Benefits:

• Satin Chromium finish
• Strike: 1-1/8″ x 2-1/4″ standard
• Latch: 2-3/8″ backset, 1-1/8″ front standard
• Cylinder: 6-pin, keyed 5, solid brass, 2 brass keys standard
• KA4: Keyed alike in four standard
• Non-handed
• Accepts 6 or 7 pin, small format, interchangeable cores
• ANSI: E0142
• Double cylinder
• Door thickness: Fits 1-3/8″ – 1-3/4″, factory set for 1-3/4″
